Ceramic Vacuum Filter
Ceramic Vacuum Filter
Application
It has been widely used in concentrates, tailings, coal,water copper, iron, gold, silver, tin, aluminum, lead, zinc, nickel, palladium, cobalt, molybdenum, aluminum, phosphorus, coal, sulfur, silicon, quartz, mica, rare earth Zinc Oxide, chemical industry lead oxide, zinc sulfide, electro slag, leaching slag, slag cement dehydration and environmental pollution as well as waste acid treatment.
Characteristics
1. High vacuum degree, low water content of filter cake.
2. The filtrate is clear and transparent.
3. Low energy consumption, lower operating cost.
4. Compact structure, easy installation and maintenance.
5. Advanced drainage system, can be suitable for use any operating conditions.
Technical Parameters
|
Model |
Filtration Area (m²) |
Number of filter plate (piece) |
Tank volume (m³) |
Operating power (kw) |
Filter disc rotation speed (r/min) |
Dimension (m) L×W×H |
|
CXTC6 |
6 |
24 |
1.4 |
<3.5 |
0.3-3 |
2700×3000×2500 |
|
CXTC10 |
10 |
60 |
1.9 |
<6.5 |
0.3-3 |
3300×2600×2200 |
|
CXTC15 |
15 |
60 |
2.9 |
<9.0 |
0.3-3 |
3900×3100×2600 |
|
CXTC21 |
21 |
84 |
3.9 |
<9.5 |
0.3-3 |
4200×3100×2600 |
|
CXTC24 |
24 |
96 |
4.4 |
<10 |
0.3-3 |
4500×3100×2600 |
|
CXTC27 |
27 |
108 |
4.9 |
<11 |
0.3-3 |
4800×3100×2600 |
|
CXTC30 |
30 |
120 |
5.4 |
<11 |
0.3-3 |
5100×3100×2600 |
|
CXTC36 |
36 |
144 |
6.5 |
<12 |
0.3-3 |
6500×3100×2700 |
|
CXTC 45 |
45 |
180 |
7.9 |
<15 |
0.3-3 |
7500×3100×2700 |
|
CXTC60 |
60 |
180 |
11.5 |
<20 |
0.3-3 |
8100×3650×3100 |
|
CXTC80 |
80 |
240 |
15 |
<22 |
0.3-3 |
9500×3650×3100 |
|
CXTC100 |
100 |
300 |
18.5 |
<30 |
0.3-3 |
11000×3600×3100 |
|
CXTC120 |
120 |
288 |
22 |
<40 |
0.3-3 |
10500×4000×3500 |
